CF-100 Carbon Disulfide Gas Sensor 200 ppm , CS2 Gas Detector In Housing Safety Control

Brand Name : MEMBRAPOR

Model Number : CS2/CF-100

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000pcs/Month

Delivery Time : 3-5Workingdays

Packaging Details : Standard Box

Operation Principle : 3-Electrode Electrochemical

Nominal Range : 0 - 100 ppm

Maximum Overload : 200 ppm

Inboard Filter : To remove acidic gases

Output Signal : 200 ± 50 nA/ppm

Resolution (Electronics dependent) : < 0.1 ppm

T90 Response Time : < 30 s

Typical Baseline Range (pure air, 20°C) : -1 ppm to 1 ppm

Maximum Zero Shift (+20°C to +40°C) : see Graph

Repeatability : < 2 % of signal

Contact Now

CS2/CF-100 Carbon Disulfide Gas Sensor In Compact Housing Safety Control



Key Features
• Highly selective and sensitive CS2 detection
• Ideal for TLV-TWA level measurements
Applications
• Discontinuous Measurement
• Safety and Process Control



Specification

Rec. Load Resistor 10 - 33 Ω
Bias (V_Sens-V_Ref) not recommended
Conformity to RoHS directive RoHS Compliance
Relative Humidity Range 15 % to 90 % RH non-condensing
Temperature Range -40 °C to 50 °C
Pressure Range Atmospheric ± 10%
Pressure Coefficient N.D.
Humidity Effect None
Expected Operation Life 2 years in air
Expected Long Term Output Drift in air < 2 % signal loss per month
Storage Life 6 months in container
Rec. Storage Temperature 5°C - 20°C
Warranty Period 12 months from date of dispatch



Temperature dependence



The output of an electrochemical sensor varies with temperature. The graphs below show the temperature-dependent variation of baseline and sensitivity, respectively. The results shown here are raw data (batch average) without any post-processing steps. The sensitivity and baseline are referenced to the signal at 20°C (reference point). Please note: It is highly recommended to acquire the temperature dependence curves with the whole instrument. The sampling system, the humidity, the electronics and the interaction between the electronics and the sensor have a significant impact on the temperature dependence of the final measurement reading.

CF-100 Carbon Disulfide Gas Sensor 200 ppm , CS2 Gas Detector In Housing Safety Control



CF-100 Carbon Disulfide Gas Sensor 200 ppm , CS2 Gas Detector In Housing Safety Control

CF-100 Carbon Disulfide Gas Sensor 200 ppm , CS2 Gas Detector In Housing Safety Control
